EP RP SERIES
EP RP SERIES
1 Phase Input / 1 Phase Output
1 KVA - 10KVA
Application
IT INFRATRUCTURE
TELECOM
MEDICAL EQUIPMENT
INSTITUTION
PRE-PRESS & PRINTING
BANK
EP RP series (1P-1P): The EP RP series UPS systems are designed using high frequency PWM voltage frequency Independent (VFI) technology with micro controller based electronic control system.
It requires minimum battery sizing (lesser no. of Batteries).
The peak surge handling capacity of 300% for 3000msc.
UPS comes with the Automatic Static Bypass switch. (Electronic Bypass).
True Inbuilt Isolation Transformer by design@ output.
IGBT based Design.
Control Designed to withstand all kinds of load.
Intelligent Battery Management to Prolong Battery Life Cycle.
CVCF (Constant Voltage Constant frequency).
High Reliability Digital control.
N+1 hot standby option uptolOunits.
Wide Input Voltage Range.
Technical Specification
| MODEL | EPRP1001 | EPRP1002 | EPRP1003 | EPRPI005 | EPRP1006 | EPRPI010 | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Capacity | 1KVA | 2KVA | 3KVA | 5KVA | 6KVA | 10KVA | |||||||||
| INPUT | |||||||||||||||
| Nominal Voltage | 220V/230V/240V AC (1Ph+N+PE, 3 Wire) | ||||||||||||||
| Operating Voltage Range | 140V~280V AC Load Dependent | ||||||||||||||
| Operating Frequency Range | 50 Hz + 1% (Auto Sensing) | ||||||||||||||
| Power Factor | >0.9 | ||||||||||||||
| OUTPUT | |||||||||||||||
| Output Voltage/Power Factor | 220V / 230V / 240V AC / +1% / 0.8 Std., 0.9 Optional | ||||||||||||||
| Output Frequency | Auto Sensing 50Hz | ||||||||||||||
| Harmonic Distortion (THDv) | <2% (Linear load), <5% (Non Liner Load) | ||||||||||||||
| Crest Factor | 3:1 | ||||||||||||||
| Efficiency | Up to 94% Dual Conversion Mode, 99% ECO Mode | ||||||||||||||
| BATTERY | |||||||||||||||
| DC Voltage | 36V | 72V | 96V | 96/180V | 144/180V | 180/192V | 180/192V | ||||||||
| Charge Current | 6.5 A Configurable | ||||||||||||||
| Recharge Time | 8 Hours (90% of full capacity) | ||||||||||||||
| SYSTEM FEATURES | |||||||||||||||
| LCD Indication | Input Voltage/Frequency, Output Voltage/Frequency | ||||||||||||||
| LED Indication | Load Level, Battery Level, Line On, Battery On, Inverter On, By Pass, Fault & Reset Button | ||||||||||||||
| Alarms / Protection | Batt. Low, DC High, Inverter Under/Over Voltage, UPS Over Load, Short Circuit, Fan Failure and UPS Fault. | ||||||||||||||
| Overload Capability | < 125% for 10 min,>125-150% for 1 min, >150% for 200 ms | ||||||||||||||
| Transfer Time | AC to Battery : Oms, Inverter to Bypass : 4ms (Typical) | ||||||||||||||
| ENVIRONMENTAL | |||||||||||||||
| Temperature | Operating: 0~40°C, Storage: -10°C ~ 55°C | ||||||||||||||
| Humidity / Altitude | 0~95% RH Non-condersing / <1500 M | ||||||||||||||
| Noise | Low Audible Noise Level | ||||||||||||||
| PHYSICAL | |||||||||||||||
| Dimension WxDxH (mm) | 12x22.5x21 | 12x22.5x21 | 12.5x22.5x25 | ||||||||||||
| Weight (Kg) | 5Kg | 35Kg | 38Kg | 40Kg | 45Kg | 50Kg | 60Kg | 70Kg | 75Kg | ||||||
| STANDARDS | |||||||||||||||
| Quality | 1SO 9000, ISO 14001, OHSAS | ||||||||||||||
| Safety | IEC/EN62040-1 | ||||||||||||||
| EMC / Performance | IEC/EN62040-2; IEC/EN62040-3, Complying to CE | ||||||||||||||
| COMMUNICATION INTERFACE | |||||||||||||||
| Standard | RS-232 Optional | ||||||||||||||
| Optional | SNMP / ModBus / Dry Contact / USB / RS-485 | ||||||||||||||
